Mobile Wood Crusher
  • Overview
  • Specification
  • case

1- Mobile Integrated Wood Crusher: Also called Mobile Wood Chipper is the first choice for the raw materials of the pre-furnace silo of the biomass power plant at home and abroad. Its compact and reasonable structure, simple operation, high production capacity, wide adaptability of raw materials, high quality of crushing granularity and high safety.
2- Application Materials: Can crush various large materials (large-diameter wood, tree roots, various weeds, etc.).
3- Capacity: 15-30t/h

wood chips

  • Tracked Mobile Wood Chipper

  • Rubber Tyred Wood Chipper

  • Rubber Tyred Wood Chipper

Model GY-T1300-500
Feed conveying (mm) 5000 *1300 (Chain plate)
Discharge conveying(mm) 1200*10000
Knife roll diameter(mm) 800
Feed port size 1300*500
Number of knives(piece) 4
Knife roll speed(r/min) 750
Processing material maximum diameter(mm) 400
Feed rate(m/min) 0-33 Variable frequency conversion
Discharge granularity(mm) 90%<80 (Different screens can be made to adjust the discharge size)
Capacity(t/h) 15-30T
Diesel power 250hp
Feed roller motor power(kw) 7.5*2
Oil pump motor power(kw) 4
Dimensions(mm) 9000*3000*2400
Chassis steel plate thickness(mm) 25
Conveying motor power(kw) 7.5
Weight(kg) 15600



Click To See Large Integrated Drum Wood Chipper For Sale (Power: 110kw-315kw | Capacity: 15-40t/h)

Click To See GY216/GY218 Drum Wood Chipper For Sale (Power: 55kw-110kw | Capacity: 5-10t/h)

Features of Mobile Wood Crusher

1) This machine adopts the foundation-free design, which can adapt to the installation and use of equipment under different geographical conditions, is not affected by seasonal climate and other external conditions, saves installation time, and saves users the manpower and material resources generated by the foundation. And financial losses.
2) This machine adopts automatic control, automatic feeding and discharging, improving production capacity, and separating human and machine, improving the safety factor of machine operation.
3) This machine adopts the chain plate to feed the material, which makes the feeding smoother and greatly improves the production capacity compared with the traditional belt feeding.
4) This machine adopts the special small tool independently developed by our company, which has long service life, low maintenance cost and high production rate.
5) This machine is equipped with a secondary discharge system, users can change the discharge direction and flexibly use according to their needs.

Use and performance of Mobile Wood Crusher

Integrated mobile wood crusher is a multi-functional crushing equipment that can crush various large materials (large-diameter wood, tree roots, various weeds, etc.). It adopts direct drive method and strong power, and can effectively and safely turn any biomass into Debris, thus acting as a biomass energy source.

Integrated mobile wood crusher is equipped with a subcontracting machine, which is suitable for processing various round straws (straw, corn stover, cotton) and other raw materials. The utility model has the advantages of compact and reasonable structure, simple operation, high production capacity, wide adaptability of raw materials, high quality of crushed granularity, high safety, convenient maintenance, and feeding by using a chain plate, which can make the feeding smoother and greatly improve the production capacity. The ideal equipment for bio-power plants.
